Garrett Pro-Pointer AT Instruction Manual - Free Digital Download

This is the Garrett instruction manual for the Pro-Pointer AT pinpointer, free to download in English, Spanish or French. Useful if you bought your pinpointer secondhand without paperwork, lost the printed copy, or simply want the settings reference on your phone when you are standing in a hole trying to remember which button sequence does what.

What the manual covers

• Powering the pinpointer on and off
• The three sensitivity levels and how to move between them
• Switching between audio alerts and vibration only
• The fast retune function
• Replacing the 9 V battery and keeping the seal watertight
• Care, cleaning and warranty service

The three things people open this manual to find

Powering on and off. Press and release the button, holding the pinpointer away from metal, to switch it on. To switch it off, press and hold the button for about half a second until you hear a single beep. A quick tap while the unit is running performs a fast retune instead, which is why a short press never shuts it down and why people assume the button is broken.

Sensitivity and Stealth Mode. Hold the button for about two seconds to enter adjustment mode, then press it repeatedly to cycle through six combinations: three sensitivity levels with audio, and the same three with vibration only. Garrett calls the vibration-only setting Stealth Mode. It is the one you want in a quiet park or anywhere a beeping pinpointer draws attention.

The battery. One 9 V, included. Rotate the battery cover counterclockwise by hand to open it and clockwise to close. No tools are needed, and tightening the cover by hand is what maintains the waterproof seal, so a loose cap is the usual cause of water getting in.

Check you have the right manual

This manual is for the standard Garrett Pro-Pointer AT, part 1140900, the orange pinpointer with no wireless. If yours has Z-Lynk wireless audio, part 1142200, download the Pro-Pointer AT Z-Lynk manual instead, since that model adds its own pairing steps. If yours is the shorter Pro-Pointer II, which is water-resistant rather than submersible, use the Pro-Pointer II manual. The pinpointer itself, if you are reading this before buying one, is the Garrett Pro-Pointer AT.

Garrett Pro-Pointer AT specifications

• Part number: 1140900
• Waterproof: submersible to 20 ft (6 m), IP68
• Battery: one 9 V, included
• Sensitivity: 3 levels
• Alerts: proportional audio and vibration, or Stealth Mode vibration only
• Fast retune to shrink the detection field around a target
• LED flashlight, and a ruler molded into the side marked in in and cm
• Lost pinpointer alarm: chirps after 5 minutes of inactivity
• Automatic power off after 60 minutes of warning chirps
• Warranty: 3 years limited parts and labor

The figures above are Garrett's current published specifications. Earlier printings of the Pro-Pointer AT manual list a 10 ft depth rating and a two year warranty, both of which Garrett has since revised upward, so go by the specifications here rather than by an old PDF if the two disagree.

How the download works

Choose your language, add it to the cart and check out at no charge. The file is then available from the order confirmation page, from the confirmation email, and from your account, so you can pull it down again later on a different device without contacting us.
